Mixer Dynacor DC-CMS600-3-MIG

• Channels 4 +2 + 2
• MIC/Line-Mono 4
• MIC/Line-Mono / USB-Stereo (Super Channel) 2
• Line L-R / CD-IN-Stereo 2
• Intuitive mixer section: with 8 input channels with 4 Mic/Line, 2 Mic/Stereo-Line, 2 Stereo-Line inputs
• 2 High-Quality FX processors, editable with 100 factory and 20 user presets
• Professional 4x4 24-bit/96kHz USB interface, recording software and MIDI interface for FX control,
• Stereo EQ for the main mix
• First-class components ( e.g. ALPS faders and potentiometers)
• Large, contrast rich OLED display
• Lightweight (5.8kg) super compact package

Mixer Dynacor CMS 600-3
8‑channel compact mixing system

• Auxiliarys (AUX, MON) Pre/Post switchable, Pre
• MIC GAIN (LINE -20 dB) +10 to +60 dB
• TRIM LINE/CD (Stereo) -10 to +20 dB
• THD, at 1 kHz, MBW = 80 kHz
• MIC input to Master A L/R outputs, +16 dBu, typical < 0.005%
• Frequency Response, -3 dB, ref. 1 kHz
• Any input to any Mixer output 15 Hz to 70 kHz
• Display 128 x 64 pixels, OLED
• Effects
• Type Dual stereo 24/48-bit multi effects processors
• Effects presets 100 Factory + 20 User, Tap-Delay
• Remote control Footswitch, MIDI
• Digital Audio Interface
• Channels 4 In / 4 Out
• AD/DA Conversion 24-bit
• Sampling Rate 44.1 / 48 / 88.2 / 96 kHz
• PC Interface USB2.0, Female Type B
• Supported OS See documentation
• MIDI Interface 5-pin DIN connector, In / Out
• Protection
• Mixer Outputs (Relay controlled) AUX, MON, MASTER A L/R
• Switching Mode Power Supply (µC controlled) Mains Over/Undervoltage
• Phantom Power, switchable 48 V DC
• Power Requirements (SMPS with auto range mains input) 100 V to 240 V AC, 50
