JBL Control 88M, Loa sân vườn nghe nhạc ngài trời Công suất : 60W Two-Way 8 inch (200mm) Coaxial Mushroom Landscape Speaker

JBL Control 88M, Loa sân vườn nghe nhạc ngài trời
Công suất : 60W Two-Way 8 inch (200mm) Coaxial Mushroom Landscape Speaker

• Components:
  • 8” highly weather-resistant driver
  • 1” soft-dome highly weather-resistant tweeter
• 120W Pink Noise Power Handling (240W program) in direct 8Ώ setting, plus built-in 60W 70V/100V multi-tap transformer
• Tough polyethylene highly weather resistant enclosure
• Fully isolated center chamber for wiring protection
• High fidelity sound character with broad frequency range of 47Hz - 16kHz

• Frequency Response (-10dB) 47 Hz – 16 kHz
• Power Rating 240 W Continuous Program (2 hrs) 120W (480W peak), Continuous Pink Noise (2 hrs) 100W (400W peak) Continuous Pink Noise (100 hrs)
• Transformer Taps 70V: 60W, 30W, 15W & 7.5W 100V: 60W, 30W, 15W
• Frequency Response (±3 dB) 60Hz - 15 kHz
• Maximum Input Voltage 28.0 V
• Sensitivity 87 dB, 1W @ 1m (ave. 80Hz - 16kHz)
• Coverage Angle 360° horizontal, 160° vertical (primary listening 10° to 50° up from ground).
• Directivity Factor (Q) 2.1
• Directivity Index (DI) 3.2 dB
• Maximum SPL (1m) 108 dB
• Impedance 8Ω (at 8Ω setting)
• Minimum Impedance 6.6Ω at 9.5kHz
• Insertion Loss <0.5 dB at any tap setting
• Thru Setting 8Ω nominal
• Crossover Type 2nd Order LPF on LF and 2nd Order HPF on HF
• Recommended Protective High-Pass 45 Hz for 8Ω operation, 24 dB/oct 80 Hz for 60W tap, 24 dB/oct 50 Hz for 30W, 7.5W, and 7.5W taps, 24 dB/oct
• Drivers LF: 200 mm (8.00 in) diameter LF driver, Kapton™ former, 38mm (1.5 in) voice coil, polypropylene cone and polyurethane surround.
• HF: 25mm (1.0 in) diameter HF driver Polyetherimide (PEI) dome.
•
• Colors Hunter Green, RAL6018
• Dimensions (H x W x D) 524 x 355 x 355 mm (20.7 x 14 x 14 in.)
• Net Weight (each) 7.8 kg (17 lb)
• Shipping Weight 10.5 kg (23 lb)
• Included Accessories (2) wire nuts, (2) gland nuts, (1) right-angle screwdriver
• Installer-Supplied Required Tools 22mm (0.875 in, 7/8 in) twist-type drill bit (or other type suitable for plastic) for installing gland nut into enclosure.
• Optional Accessories 22mm (0.875 in, 7/8 in) twist-type drill bit (or other type suitable for plastic) for installing gland nut into enclosure.
