JBL Control 85M Two-Way 5.25 inch (135mm) Coaxial Mushroom Landscape Speaker

 JBL Control 85M
Two-Way 5.25 inch (135mm) Coaxial Mushroom Landscape Speaker

• Frequency Response (-10dB) 55 Hz – 18 kHz
• Power Rating 160 W Continuous Program (2 hrs) 80 W (320W peak), Continuous Pink Noise (2 hrs) 45 W (180W peak) Continuous Pink Noise (100 hrs)
• Transformer Taps 70V: 30W, 15W, 7.5W & 3.8W 100V: 30W, 15W, 7.5W
• Frequency Response (±3 dB) 65Hz - 16 kHz
• Maximum Input Voltage 23.3 V
• Sensitivity 86 dB, 1W @ 1m (ave. 80Hz - 16kHz)
• Coverage Angle 360° horizontal, 160° vertical (primary listening 10° to 50° up from ground).
• Directivity Factor (Q) 2.2
• Directivity Index (DI) 3.4 dB
• Maximum SPL (1m) 105 dB
• Impedance 8Ω (at 8Ω setting)
• Insertion Loss <1.0 dB at any tap setting
• Thru Setting 8Ω nominal
• Crossover Type 2nd Order LPF on LF and 2nd Order HPF on HF
• Recommended Protective High-Pass 65 Hz for 8Ω operation, 24 dB/oct 60 Hz for 30W tap, 24 dB/oct 50 Hz for 15W, 7,5W, and 3.7W taps, 24 dB/oct
• LF Driver LF: 135 mm (5.25 in) diameter LF driver, Kapton™ former, 35.5mm (1.4 in) voice coil, polypropylene cone and polyurethane surround.
• HF: 19mm (0.75 in) diameter HF driver Polyetherimide (PEI) dome.
• Enclosure LDPE Polyethylene plastic, 6 mm wall thickness, UL94V-0 rated.
• Grille Powder coated stainless steel.
• Outdoor Capability IP-55 rating per IEC529 (dust protected and protected against jets of water). Exceeds MilSpec 810 for humidity, salt spray, temperature & UV. Passes Mil-STd-202F for salt spray. Enclosure UL94V0 rated.
• Safety Agency UL1480, Transformer UL Recognized per UL1876, ROHS compliant.
• Input Connectors Bare wire with dielectric-gel-filled wire nuts (internal to top speaker section).
