Bộ chuyển đổi ngõ vào IP 1CH InterM IP-1000AB

Bộ chuyển đổi ngõ vào IP 1CH InterM IP-1000AB

Product Features
IP-1000AB is a device that receives an analog audio signal, converts it with a digital audio signal, and then transmits. You can easily send sound sources to the network by using it with the IP speaker/IPA system. Small size is efficient in reducing the installation space and reducing costs.


■ Inter-M AOE-based network audio transmitter

■ Can be used with Inter-M IP speaker/IPA system

■ 1CH line audio input

■ WAV, MP3 file streaming available

■ It is possible to integrate with external devices through contact input and output.

■ 1GB of internal memory for storing music sources  (Up to 32GB of expansion through MicroSD card)

■ Device control through the Web GUI

■ Support for installation of table types or walls

• Maximum Input Level(Balanced):+6dBV(2Vrms)
• Frequency Response: 20Hz ~ 20kHz(±3dB)
• THD(@ +0dBV 1kHz Sine Wave In,
• IP-1015BX LINE OUTPUT, AES17 20kHz LPF)    :≤ 0.05%
• S/N(@ +6dBV 1kHz Sine Wave In,
• IP-1015BX LINE OUTPUT, AES17 20kHz LPF, A-WTD)    :≥ 92dB
• Contact Input(1CH): Dry Contact
• Contact Output(1CH):Dry Contact(N.O : Normally Open)
• Internal Storage: 1GB
• MicroSD: Up to 32GB(SDHC)
• Ethernet: 10/100 BASE-TX PoE
• Connectors:Ethernet Jack(RJ-45)
• Power: PoE(IEEE 802.3af) or DC Min : 8V, Max : 28V
• Operating Temperature: -20℃ ~ +50℃
• Power Consumption: PoE(IEEE 802.3af) : 44~57 VDC, Max 90mA, DC : 8~28V, Max 320mA
• Weight(Set):0.24kg
• Dimensions(Set)    :123(W) x 80(H) x 30.6(D)mm
